Question 1

Technology

Accepted Answer

Olycal® Stone: After 7 years of research and development, Atelier CINIER developed Olycal® Stone: Olycal stone is crushed in the first stage of production and then restructured in the Cinier workshop using a special patented process that ensures high-efficiency heat distribution.Heating element: HYDRONIC model (European standards EN442-2, tested by Cetiat laboratory) or ELECTRIC model (CE electrical).Enhanced version: a new option that allows you to increase heating power by 40% in hot water or electric versions.Energy saving: By tailoring your radiator's power to your actual needs, the CINIER thermostat can reduce your energy requirements by up to 20%.Enhanced comfort: While radiating thermal and radiant heat, the CINIER radiator allows for even heat distribution without creating carbonized dust and pollution. Furthermore, the products remain completely silent.

Question 2

Setup

Accepted Answer

Electrical connection:Standard 230V supply - X3D thermostat included – Installation instructions available upon request.Hydronic version connection:A height difference of 3 cm between the starting point and the turn, with a distance of 20 cm from the center – Notifications and connection diagrams will be provided upon request.Thermostatic valves, adjustment tees, and flexible hoses are supplied as standard with every CINIER radiator.

Question 3

Exceptional comfort.

Accepted Answer

Every CINIER radiator is meticulously researched and designed to deliver exceptional heating comfort.Our technology is based on 3 principles:The brilliance of Olycal® stoneOlycal® stone's thermal inertiaLow emissions thanks to the radiator's large surface area and electronic control.Olycal® stone is a natural white rock (from the Pyrenees mountains in southern France) that has been crushed and reprocessed to ensure exceptional diffusion of thermal energy. Like cast iron, Olycal® stone emits heat smoothly and homogeneously at low temperatures. CINIER radiators are completely silent.

Question 4

Thermal mass effect

Accepted Answer

Thermal mass effect (or inertia): The thermal mass of the Olycal® stone ensures the "accumulation" and "reducible deposition" of heating emissions. This allows for comfortable, constant, homogeneous heat diffusion, maintaining the room at the correct temperature with exceptional comfort. Low-temperature heating: The large surface area and electronic control of CINIER radiators allow for low-temperature heating without forced air flow (total silence of operation). The air in the room is not dry, making it healthier and more pleasant to breathe.

Question 5

Water heated version

Accepted Answer

For a boiler and hydronic system: Heating core: The heating body is made of heavy copper tubes (ranging from 50 to 60 meters), with an anti-corrosion and anti-dillation outer layer that guarantees silence and reliability. Tested at 25 bar, the CINIER heating body ensures optimum performance and exceptional robustness. The heating body is fully integrated into the Olycal® stone thanks to a special technological process. It also heats the mineral mass throughout its surface, radiating from a natural, persistent heat. All hydronic radiators from CINIER comply with EN442-2 regulations (Delta T50). Their quality and safety are checked and guaranteed. Heat generation at 75° / 65° / * * C (Delta T50) - For different water temperatures, please contact us.

Question 6

Electric version

Accepted Answer

Heating core: The heating core is made with a heating cable using a specific double insulation layer that will not deteriorate over time. Our radiators are equipped with double insulation and 2-meter capillary thermo-sensitization safety to prevent overheating. Electric models are Class II. The heating core is fully integrated into the Olycal stone thanks to an exclusive technological process. It also heats the mineral mass throughout the superstructure of the radiator, radiating a natural, persistent heat. Connections: Electrical plug only. Electric Olycal® CINIER heaters are available for the US market in 230 V or 120 V. Other voltages are available upon request.

Question 7

Links

Accepted Answer

Connections: The outlet of the water pipes can be built into the wall (to avoid seeing the pipe without a summary). Connection & size diagram available upon request. Adapter: Made by 1/2 male hose pipes bent inside the junction. Supplied with bends, joint adjustment and flexible radiator. Outlet: Heating at 75°/65°/2°C (delta T50) - Please contact our office for different water temperatures. Our production is controlled by an international specialized laboratory.

Question 8

Thermostat

Accepted Answer

Regulation / Electronic Thermostat: CINIER electric radiators at 230V are equipped with: – a proportional integrated electronic RTS regulation. The principle is simple: the RTS regulation continuously and proportionally adjusts the output of your radiators to your thermal needs. The interaction between the thermal mass of the Olycal® stone and the RTS regulator is highly efficient and provides noticeable energy savings. or – a radio-controlled programmable thermostat from DeltaDore. Wall-mounted or floor-mounted, the thermostat is easily accessible with a programmable timer (24/7) for setting the temperature overnight or while away. By adapting the power of your radiator to your actual needs, the CINIER thermostat can reduce your energy requirements by up to 20%. All CINIER electric models are CE and NF listed.
